Vantageo 2530-WT
Vantageo 2530-WT is a high-performance, enterprise-grade server platform built to deliver exceptional computing power, scalability, and advanced security features. Supporting dual 3rd Gen Intel® Xeon® Scalable processors and up to 4TB of memory, this 5U rack server is ideal for demanding workloads, virtualization, and high-capacity storage environments. With robust RAID capabilities, embedded management, and optional redundant power supply, it ensures reliability and seamless integration in modern data centers.
Technical Specifications
| Component | Details |
|---|---|
| Processor | Dual 3rd Generation Intel® Xeon® Scalable processors, up to 40 cores each |
| Chipset | Intel C621A |
| Memory | 16 DDR4 ECC DIMM slots; supports RDIMM / RDIMM 3DS / LRDIMM / LRDIMM 3DS, up to 3200 MT/s; Max 4TB |
| Drive Bays | Front: Up to 4 x 2.5” and 4 x 3.5” SAS/SATA (HDD/SSD) |
| RAID Support | Onboard Intel RSTe: RAID 0/1/10/5; RAID controller options supporting RAID 0/1/5/6/10/50/60 |
| Storage Interfaces | SATA - 14 x SATA3 (6Gbps); NVMe - M.2 (2 x 22110/2280 PCIe), U.2 (2 x SFF-8654 for 4 NVMe ports) |
| Expansion Slots | 2 x PCIe Gen4 x8, 3 x PCIe Gen4 x16 |
| I/O Ports | 2 x USB 3.0 (rear), 2 x COM headers, 1 x VGA (D-Sub 15-pin), 1 x TPM Header |
| LAN Ports | 2 x GbE ports + 1 x GbE dedicated for IPMI |
| Management | IPMI 2.0 compliant BMC with 10/100/1000 Mb/s MAC, embedded monitoring, USB boot, PXE, Console Redirection, ACPI 6.1 |
| Form Factor | Rackmount (5U) |
| Dimensions | Height: 178mm, Width: 452mm, Length: 647mm (Max. weight: 28 kg) |
| Power Supply | Optional Redundant CRPS 1+1: 800W / 1200W / 1600W (Titanium) |
| Operating Systems | Microsoft Windows Server®, RHEL, SUSE Linux Enterprise Server, Ubuntu Server LTS, VMware ESXi |
| Security | Secure Boot, TPM 1.2/2.0 optional, Cryptographically signed firmware |
| Operating Temperature | 10°C to 35°C |
| Storage Temperature | -40°C to 70°C |
| Humidity | Non-operating: up to 90%, non-condensing at 35°C |
| Support Options | NBD, 24x7 - 4hrs Response, CTR options (Next Business Day / 24hr / 6hr resolution) |
No software files available for this model yet.
No firmware files available for this model yet.
