Vantageo 2530-WS
The Vantageo 2530-WS is a high-performance 5U rack server built to meet demanding enterprise workloads. Featuring dual 3rd Generation Intel® Xeon® Scalable processors, support for up to 4TB of DDR4 ECC memory, and robust RAID and storage capabilities, this system offers enhanced scalability, security, and manageability. It is ideal for data-intensive environments, virtualization, and mission-critical applications, with flexible support and power configurations. With hot-swappable drive bays, redundant power supplies, and flexible networking options, it ensures minimal downtime and maximum availability.
Integrated BMC with IPMI 2.0 support allows for secure remote management and monitoring, even when the system is offline.
Comprehensive security features include TPM 2.0, secure boot, and hardware-level encryption for data protection.
Technical Specifications
| Component | Details |
|---|---|
| Processor | Dual 3rd Gen Intel® Xeon® Scalable processors, up to 40 cores each |
| Chipset | Intel C621A |
| Memory | 18 DDR4 ECC DIMM slots, Supports RDIMM / RDIMM 3DS / LRDIMM / LRDIMM 3DS, up to 3200MT/s, 4TB max |
| Drive Bays | Front: Up to 4 x 2.5" SAS/SATA (HDD/SSD), Up to 4 x 3.5" SAS/SATA (HDD/SSD) |
| RAID Support | Onboard Intel RSTe: RAID 0/1/10/5; Additional controller options: RAID 0/1/5/6/10/50/60; Cache: 2GB/4GB/8GB |
| Storage Interfaces | 14 x SATA3 (6Gbps); 2 x NVMe M.2 (2280/22110) via PCIe |
| Expansion Slots | 4 x PCIe 4.0 x16, 2 x PCIe 4.0 x8 |
| LAN | 2 x RJ45 Gigabit Ethernet ports |
| USB Ports | 7 x USB 3.2 Gen1 (2 header, 4 rear, 1 front type-A), 2 x USB 2.0 (via header) |
| Serial Ports | 2 x COM ports (1 rear, 1 header) |
| Video Output | 2 x VGA (1 front panel, 1 rear) |
| TPM | 1 TPM header, TPM 2.0 Optional |
| Security | Silicon Root of Trust (RoT), Secure Firmware Updates, Automatic Firmware Recovery |
| Form Factor | Rackmount (5U) |
| Dimensions | Height: 178mm, Width: 452mm, Length: 647mm, Max Weight: 28kg |
| Power Supply | Redundant CRPS 1+1, 800W/1200W/1600W (TITANIUM) |
| Management | IPMI 2.0, Virtual Media over LAN, KVM-over-LAN, Embedded BMC |
| Operating Temperature | 10°C to 35°C |
| Storage Temperature | -40°C to 70°C |
| Humidity | 5% to 95% non-condensing |
| Supported OS | Windows Server, Red Hat® Enterprise Linux, SUSE® Linux Enterprise Server, Ubuntu® Server LTS, VMware® ESXi |
| Support Options | NBD, 24x7 - 4 Hours Response with Call to Resolution (CTR) up to 6 hours |
