2230-WT

Vantageo 2230-WT

The Vantageo 2230-WT is a 5U rackmount server engineered for scalable performance and flexible configuration. Designed with support for dual 3rd Gen Intel® Xeon® Scalable processors, high-capacity DDR4 memory, robust I/O, and multiple PCIe Gen 4 slots, it is ideal for compute-intensive and virtualization-heavy enterprise workloads. Built-in security, intelligent management, and high-density storage make it a reliable platform for modern data centers.

Technical Specifications

Category	Specification
Model	Vantageo 2230-WT
Form Factor	Rackmount (5U)
Processor Support	Dual Socket P+ (LGA-4189), 3rd Gen Intel® Xeon® Scalable, up to 40 cores, 270W TDP
Chipset	Intel® C621A
Memory Type	DDR4 ECC RDIMM/LRDIMM/3DS, Intel® Optane™ Persistent Memory
Memory Speed	Up to 3200 MT/s
Memory Slots	16 DIMM slots
Max Memory Capacity	Up to 4TB
Drive Bays (Front)	Up to 4x 3.5" or 4x 2.5" SAS/SATA (HDD/SSD)
Storage Support	SAS/SATA/NVMe; RAID 0/1/5/6/10/50/60; Intel RSTe
M.2 Support	2x PCIe 4.0 x4 (2280/22110, RAID 0 & 1)
Expansion Slots	5x PCIe 4.0 x16, 1x PCIe 4.0 x8, 4x PCIe 4.0 NVMe x4 internal ports
I/O Ports	2x COM, 7x USB 3.2 Gen1, 2x USB 2.0, 2x VGA
Networking	2x RJ45 1GbE LAN ports
Management	IPMI 2.0 with virtual media, KVM-over-LAN
Security	TPM 2.0, Silicon Root of Trust, Secure Firmware, NIST 800-193 Compliant
Operating Temp.	10°C to 35°C (50°F to 95°F)
Non-Operating Temp.	-40°C to 70°C (-40°F to 158°F)
Humidity	5% to 95% (Non-Condensing)
Dimensions (HxWxL)	452 x 178 x 647 mm
Weight	Max. 28 kg
Power Supply	Optional Redundant CRPS, 1+1 800/1200/1600W (Titanium)
Supported OS	Windows Server®, Red Hat®, SUSE®, Ubuntu®, VMware® ESXi

Vantageo – 2230-WT

Document

Software

Firmware

Vantageo – 2230-WT Datasheet New

Version: R1.0 | 2025 | PDF

⬇ Download

No software files available for this model yet.

No firmware files available for this model yet.

Download Product Datasheet

Download Product Description

Download Product Manual

Download Product Drivers

Download Product - Bios

Download Product Firmware

Vantageo 2230-WT

The Vantageo 2230-WT is a 5U rackmount server engineered for scalable performance and flexible configuration. Designed with support for dual 3rd Gen Intel® Xeon® Scalable processors, high-capacity DDR4 memory, robust I/O, and multiple PCIe Gen 4 slots, it is ideal for compute-intensive and virtualization-heavy enterprise workloads. Built-in security, intelligent management, and high-density storage make it a reliable platform for modern data centers.

Technical Specifications

Category	Specification
Model	Vantageo 2230-WT
Form Factor	Rackmount (5U)
Processor Support	Dual Socket P+ (LGA-4189), 3rd Gen Intel® Xeon® Scalable, up to 40 cores, 270W TDP
Chipset	Intel® C621A
Memory Type	DDR4 ECC RDIMM/LRDIMM/3DS, Intel® Optane™ Persistent Memory
Memory Speed	Up to 3200 MT/s
Memory Slots	16 DIMM slots
Max Memory Capacity	Up to 4TB
Drive Bays (Front)	Up to 4x 3.5" or 4x 2.5" SAS/SATA (HDD/SSD)
Storage Support	SAS/SATA/NVMe; RAID 0/1/5/6/10/50/60; Intel RSTe
M.2 Support	2x PCIe 4.0 x4 (2280/22110, RAID 0 & 1)
Expansion Slots	5x PCIe 4.0 x16, 1x PCIe 4.0 x8, 4x PCIe 4.0 NVMe x4 internal ports
I/O Ports	2x COM, 7x USB 3.2 Gen1, 2x USB 2.0, 2x VGA
Networking	2x RJ45 1GbE LAN ports
Management	IPMI 2.0 with virtual media, KVM-over-LAN
Security	TPM 2.0, Silicon Root of Trust, Secure Firmware, NIST 800-193 Compliant
Operating Temp.	10°C to 35°C (50°F to 95°F)
Non-Operating Temp.	-40°C to 70°C (-40°F to 158°F)
Humidity	5% to 95% (Non-Condensing)
Dimensions (HxWxL)	452 x 178 x 647 mm
Weight	Max. 28 kg
Power Supply	Optional Redundant CRPS, 1+1 800/1200/1600W (Titanium)
Supported OS	Windows Server®, Red Hat®, SUSE®, Ubuntu®, VMware® ESXi
