  • VB1100-32Q

VB1100-32Q

The Vantageo 1240-RE is a new-generation 1U 2-socket general rack server that supports two Intel® Xeon® 4th/5th generation scalable processors (Eagle Stream). Designed with a high-density, modular, and streamlined architecture, it delivers high performance, high reliability, easy expansion, and simplified management. This makes it ideal for Internet, cloud computing, big data, and virtualization applications.

Technical Specifications

Form Factor1U rack server
Cabinet19-inch ≥1,000mm-deep cabinet
ChipsetIntel C741
Processor1/2 Intel® 4th/5th Gen Xeon® Scalable (Eagle Stream), up to 64 cores per CPU
CPU Interconnect3 UPI links, 20GT/s
Memory32 DDR5 slots, max 5,600MT/s, Advanced ECC
DIMM Options16GB/32GB/64GB/128GB/256GB DDR5-5600/4800
RAID Support0/1/5/6/10/50/60 with power-off protection
Front Storage10x 2.5" hot-swap (SAS/SATA/NVMe SSD)
Near Storage2x 2.5" hot-swap (optional SAS/SATA/NVMe SSD)
Max NVMe SSDs12
PCIe Slots6 total (3 standard, 2 OCP 3.0 NIC, 1 RAID card)
GPU Support2 high-performance GPUs
Power Supply1+1 redundant, 550W/800W/1200W/1600W/2000W (Platinum/Titanium)
Input Voltage110V/220V AC, 240V/336V HVDC, -48V DC
Cooling8 hot-swappable fans, N+1 redundancy
ManagementIPMI/SNMP/Redfish, Vantageo Server Suite, KVM
SecurityTPM, Secure Boot, Authenticated BIOS
USB Ports2x rear USB 3.0, 1x front USB 3.0, 1x internal USB 3.0, 1x front USB 2.0
Video Ports2x VGA (front + rear)
Serial Port1x
Dimensions432mm (W) × 43mm (H) × 780mm (D)
Weight≤27kg (full config, no rails)
Operating Temp+5°C to +45°C (config-dependent)
Humidity8–90% RH (operating), 5–95% RH (storage)
Altitude≤3,000m (no HDDs above 3,000m)
